3/4" Dr. Cr-Mo Torx Star Torque Tamperproof Socket Bits Individual:T70,80,90,100

No.VT13245T

SKU: 1307113245-T70

0.0 (0)

AUD16.00

Received successfully

Coupon Code

CONTINUE SHOPPING

Add to Favorites (1)

3/4" Dr. One piece forging for extra strength.
Manufactured from Chrome Molybdenum.
57mm full length tamperproof torx star bits with center hole.
Multi-variation list with option size: T70,T80,T90,T100

Over torque may damage the socket. Please refer the max. tourque range chart on the below:

Size	Inch P to P	Metric P to P	Maximum Torque Range
T1	.031	.81mm	.02 to .03 Nm
T2	.036	.93mm	.07 to .09 Nm
T3	.046	1.10mm	.14 to .18 Nm
T4	.050	1.28mm	.22 to .28 Nm
T5	.055"	1.42 mm	.43 to .51 Nm
T6	.066"	1.70 mm	.75 to .9 Nm
T7	.078"	1.99 mm	1.4 to 1.7 Nm
T8	.090"	2.31 mm	2.2 to 2.6 Nm
T9	.098"	2.50 mm	2.8 to 3.4 Nm
T10	.107"	2.74 mm	3.7 to 4.5 Nm
T15	.128"	3.27 mm	6.4 to 7.7 Nm
T20	.151"	3.86 mm	10.5 to 12.7 Nm
T25	.173"	4.43 mm	15.9 to 19 Nm
T27	.195"	4.99 mm	22.5 to 26.9 Nm
T30	.216"	5.52 mm	31.1 to 37.4 Nm
T40	.260"	6.65 mm	54.1 to 65.1 Nm
T45	.306"	7.82 mm	86 to 103.2 Nm
T50	.346"	8.83 mm	132 to 158 Nm
T55	.440"	11.22 mm	218 to 256 Nm
T60	.519	13.25 mm	379 to 445 Nm
T70	.610	15.51 mm	630 t0 700 Nm
T80	.690	17.54 mm	943 to 1048 Nm
T90	.784	19.92 mm	1334 to 1483 Nm
T100	.871	22.13 mm	1843 to 2048 Nm

1/1

Description

Over torque may damage the socket. Please refer the max. tourque range chart on the below:

Size	Inch P to P	Metric P to P	Maximum Torque Range
T1	.031	.81mm	.02 to .03 Nm
T2	.036	.93mm	.07 to .09 Nm
T3	.046	1.10mm	.14 to .18 Nm
T4	.050	1.28mm	.22 to .28 Nm
T5	.055"	1.42 mm	.43 to .51 Nm
T6	.066"	1.70 mm	.75 to .9 Nm
T7	.078"	1.99 mm	1.4 to 1.7 Nm
T8	.090"	2.31 mm	2.2 to 2.6 Nm
T9	.098"	2.50 mm	2.8 to 3.4 Nm
T10	.107"	2.74 mm	3.7 to 4.5 Nm
T15	.128"	3.27 mm	6.4 to 7.7 Nm
T20	.151"	3.86 mm	10.5 to 12.7 Nm
T25	.173"	4.43 mm	15.9 to 19 Nm
T27	.195"	4.99 mm	22.5 to 26.9 Nm
T30	.216"	5.52 mm	31.1 to 37.4 Nm
T40	.260"	6.65 mm	54.1 to 65.1 Nm
T45	.306"	7.82 mm	86 to 103.2 Nm
T50	.346"	8.83 mm	132 to 158 Nm
T55	.440"	11.22 mm	218 to 256 Nm
T60	.519	13.25 mm	379 to 445 Nm
T70	.610	15.51 mm	630 t0 700 Nm
T80	.690	17.54 mm	943 to 1048 Nm
T90	.784	19.92 mm	1334 to 1483 Nm
T100	.871	22.13 mm	1843 to 2048 Nm
